VBA para crear una tabla de Word con bordes

VBA

Módulo estándar

Cuando se desea escribir información tabular en Word, la creación de una tabla para almacenar los datos funciona a la perfección. El procedimiento WordMakeTable_s4p devuelve el objeto de tabla que se acaba de crear.

La tabla es una matriz bidimensional y cada celda se puede referenciar con:

oTable.cell(RowNumber, ColumnNumber).Range.Text = "whatever you want"

Dónde:

oTable es la referencia del objeto para la tabla

RowNumber, ColumnNumber es el número entero largo de fila y columna

'*************** Code Start *****************************************************
' module name: mod_Word_MakeTable_s4p
'-------------------------------------------------------------------------------
' Purpose  : VBA to create a table in Word
'              send document and range objects
'              specify number of rows and columns
'              optionally add Caption
'              optionally add borders and shading to first row
'              optionally send column headings
' Author   : crystal (strive4peace)
' Code List: www.MsAccessGurus.com/code.htm
' This code:
' LICENSE  :
'   You may freely use and share this code, but not sell it.
'   Keep attribution. Use at your own risk.
'-------------------------------------------------------------------------------
'~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
'           WordMakeTable_s4p
'~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
Public Function WordMakeTable_s4p(oDoc As Object _
   ,oRange As Object _
   ,ByVal pnRows As Long _
   ,ByVal pnCols As Long _
   ,Optional ByVal psCaption As String =  "" _
   ,Optional pbDoBorders As Boolean = True _
   ,Optional ByVal paHeadArray As Variant _
   ) As Object  'As Word.Table
'strive4peace 170811, 20202, 220420, 230619 array headings, 22
   ' PARAMETERS
   '  oDoc os the document object
   '  oRange is a range object where to insert table
   '  pnRows is a long integer number of rows
   '  pnCols is a long integer number of columns
   ' OPTIONAL
   '  psCaption os a caption -- start with space or period space
   '  pbDoBorders = True to add borders and shading for the first row
   '  paHeadArray os a vriant array with column headings

   'early binding
'   Dim oTable As Word.Table

   'late binding
   Dim oTable As Object

   Dim i As Integer _
      ,iCol As Integer

   'insert table
   With oDoc
      Set oTable = .Tables.Add( _
         Range:=oRange _
         ,NumRows:=pnRows _
         ,NumColumns:=pnCols _
         )

   End With

   If (psCaption   "") Then
      'insert caption
      oDoc.Application.Selection.InsertCaption _
            Label:= "Table" _
            ,Title:=psCaption _
            ,Position:=0 _
            ,ExcludeLabel:=0
   End If

   With oTable
      'Position - wdCaptionPositionAbove=0
'      .ApplyStyleHeadingRows = True
      .TopPadding = 0
      .BottomPadding = 0
      .LeftPadding = 2  'points
      .RightPadding = 2
      .Spacing = 0  'Auto
      .AllowPageBreaks = True
      .AllowAutoFit = False

      'dont allow rows to break
      .Rows.AllowBreakAcrossPages = False

      'no space above text between paragraphs
      .Range.Paragraphs.SpaceBefore = 0

      'Vertical Alignment is Center
      .Range.Cells.VerticalAlignment = 1  ' 1=wdCellAlignVerticalCenter

      'Heading Row
      If Not IsMissing(paHeadArray) Then
         'mark heading row
         .Rows(1).HeadingFormat = True
         iCol = 1
         For i = LBound(paHeadArray) To UBound(paHeadArray)
            .Cell(1,iCol).Range.Text = paHeadArray(i)
            iCol = iCol + 1
         Next i  'array element
      End If

      If pbDoBorders Then
         Call WordTableBorders_s4p(oTable)
      End If

      'best-fit columns
      .Columns.AutoFit

   End With

   Set WordMakeTable_s4p = oTable

End Function

'~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
'           WordTableBorders_s4p
'~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
'Object is 'Word.Table
Public Sub WordTableBorders_s4p(oTable As Object)
's4p 170811
   Dim i As Integer
   With oTable
      For i = 1 To 6
         'wdBorderTop =-1
         'wdBorderLeft = -2
         'wdBorderBottom =-3
         'wdBorderRight= -4
         'wdBorderHorizontal = -5
         'wdBorderVertical = -6
         With .Borders(-i)
            .LineStyle = 1   'wdLineStyleSingle=1
            .LineWidth = 8  'wdLineWidth100pt=8. wdLineWidth150pt=12
            .Color = RGB(200,200,200)  'medium-light gray
         End With
      Next i
   End With
   'change borders to black for first row
   With oTable.Rows(1)
      For i = 1 To 4
         With .Borders(-i)
            .Color = 0       'wdColorBlack = 0
         End With
      Next i
      'Shading for header row
      .Shading.BackgroundPatternColor = RGB(232,232,232)
   End With  'first row
   'Not used:
'      'wdLineStyleNone = 0
'      .Borders(-7).LineStyle = 0 'wdBorderDiagonalDown =-7
'      .Borders(-8).LineStyle = 0 'wdBorderDiagonalUp =-8
End Sub

'~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
'           test_WordMakeTable
'~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
'mod_test_WordMakeTable_s4p
Public Sub test_WordMakeTable()
'230619 s4p
' make a table where the cursor is in the active document,
'  in a new next paragraph

   'CLICK HERE
   'Press F5 to run for ActiveDocument

   Dim oRange As Word.Range

   Dim nRows As Long _
      ,nCols As Long _
      ,i As Integer _
      ,sCaption As String

   '------------------------- CUSTOMIZE!
   Dim aHeadings(1 To 4) As Variant
   nRows = 2
   nCols = 4
   '-------------------------

   sCaption =  " Table containing " _
      & nRows &  " rows, and " _
      & nCols &  " columns" _
      &  " with borders and best-fit columns"

   'make up fake column names
   For i = 1 To nCols
      aHeadings(i) =  "Column " & i
      'make heading longer for last column
      If i = nCols Then
         aHeadings(nCols) = aHeadings(nCols) _
            &  " is a description so it's wider"
      Else
         aHeadings(nCols) = aHeadings(nCols) _
            &  " Heading"
      End If
   Next i

   '-------------------------
   'collapse to end of selection
   Set oRange = Selection.Range
   With oRange
      .Collapse 0  'wdCollapseEnd
      'insert new paragraph
      .InsertParagraphAfter
      .Collapse 0  'wdCollapseEnd
   End With

   'make table with caption, with borders, heading labels
   Call WordMakeTable_s4p( _
      ActiveDocument _
      ,oRange _
      ,nRows _
      ,nCols _
      ,sCaption,True,aHeadings)

   MsgBox  "Done making table",, "Done"

End Sub
'*************** Code End *******************************************************
